Diamond Eco Solutions has developed an advanced scrubber system designed to effectively reduce volatile organic compounds (V.O.C.s) released into the atmosphere. The system operates using a series of three interconnected tanks that work together to clean and purify exhaust emissions. Each stage of the process is specifically engineered to progressively scrub the exhaust, utilizing liquid surfactants and carbon filtration to ensure that pollutants are significantly reduced before the exhaust is safely released. This multi-step approach enhances the system’s efficiency in capturing harmful compounds, contributing to cleaner emissions and a more environmentally friendly operation.

VOC Reduction System (Carbon Steel)

Global Vacuum Systems VOC reduction system is engineered for effective emissions control. This three-tank system ensures reliable operation with built-in redundancy.

System Design

• Configuration: 3-tank system

  • (1) Surfactant tank

  • (2) Carbon tanks

• Flow Path: Exhaust from the vacuum system runs through the surfactant tank and then out one of the carbon tanks, with the second carbon tank serving as backup.

Tank Specifications

• Surfactant Tank:

  • 30″ diameter

  • Full open lid

  • Demister pad

• Carbon Tanks (x2):

  • 30″ diameter each

  • Full opening lid

  • Vibrator for carbon extraction
